AGPS-1-3 Parallel Gripper – Single Finger, One Fixed Jaw

Features & Benefits

T-Slot bearing support for the carriage and end plate offers superior load bearing performance throughout the stroke.
Compact lightweight unit with built-in air cylinder.
Piston seals are U-cup type for long service life.
Standard built-in stroke adjustment and stroke lock for precise, repetitive operation.
Hall Effect sensors are available to monitor stroke position.
Multiple mounting surfaces on the body and endplate with threaded and counterbored holes for easy mounting choices.

Measurement Type

Sensor Options

Sensor Type

Sensor Connector

Clear

Design: Built-in air cylinder T-slot slide

Stroke: 1.5 in [38.1 mm]

Thrust Force @ 80 PSI [5.5 BAR]

Extended: 15 lbs [66.7 N]

Retract: 13 lbs [57.8 N]

Recommended Speed: 2-12 in/sec [0.5-.3m/sec]

Pressure Range:
Low/High 20-120 PSI [1.4-8 BAR]

Temperature Range:
Low/High -20°/150°F [-28°/80°C]

Side Play: ± 0.001 [.03 mm]

Maximum Payload: 12 lbs [5.4 kg]

Material: High Strength, Aluminum Alloys, Bronze

Weight: 4 oz [113 g]

Piston Diameter: .50 in [12.7 mm]
